Baumer FS 90
Speed switches
- Mechanical speed monitoring based on centrifugal force
- Fixed switching speed
- Switch with insulated make and break contact
| Switching accuracy: | ± 4 % (Δn = 2 rpm/s); 20 % (Δn = 1500 rpm/s) |
|---|---|
| Approval: | CE |
| Emitted interference: | EN 61000-6-3 |
| Interference immunity: | EN 61000-6-2 |
| Minimum switching current: | 50 mA |
| Output switching capacity: | ≤6 A / 230 VAC ≤1 A / 125 VDC |
| Switching outputs: | 1 output, speed control |
| Switching hysteresis: | 40 % of switching speed |
| Switching deviation: | ≤3 % (cw-ccw rotation) |
| Admitted shaft load: | ≤150 N axial ≤250 N radial |
|---|---|
| Operating temperature: | -40...+130 °C |
| Corrosion protection: | IEC 60068-2-52 Salt mist for ambient conditions C4 according to ISO 12944-2 |
| Weight approx.: | 900 g |
| Connection: | Terminal box |
| Rotor moment of inertia: | 0,35 kgcm² |
| Operating torque: | ≤2 Ncm |
| Range of switching speed (ns): | 850...4500 rpm (Δn = 2 rpm/s) |
| Speed (n): | ≤1,25 · ns |
| Protection DIN EN 60529: | IP 55 |
| Flange: | EURO flange B10 |
| Shaft type: | ø11 mm solid shaft |
| Size (flange): | ø115 mm |
| Material: | Housing: aluminium die-cast Shaft: stainless steel |
