Baumer Rotary Encoders

Speed switches SIL3 and PLe certificationMonitoring of underspeed, overspeed, standstill and rotating directionInputs for 1 SinCos encoder (SIL3/PLe) and 2 HTL/PNP control signalsSafety related outputs and signal splitterMounting to 35 mm DIN rail (according to EN 60715)USB interface for simple para ...

Incremental encoders Size ø58 mmPrecise optical sensing (interpolated)Output signal level programmable (TTL or HTL)Synchro flangeConnection axial, radial or tangentialPulses per revolution 1...65536, programmableHigh protection up to IP 67High resistance to shock and vibrations

Tachogenerators Low response timeOpen circuit voltage 10...20 mV per rpmBlind hollow shaft ø12...16 mm or cone shaft ø17 mm (1:10)High signal quality due to patented LongLife technologyNo auxiliary energy source required

Hall sensors cable PUR, 2 m-40 … 85 °C

Incremental encoders - combination Compact, robust die-cast housingFlange connector with metal mating connectorEURO flange B10 / solid shaft ø11 mmTemperature compensation of tacho voltage as standardOpen circuit voltage 10...60 mV per rpm

Speed switches Mechanical speed monitoring based on centrifugal forceFixed switching speedSwitch with insulated make and break contact

Incremental encoders Robust, compact housing Two bearings with large distance, one at each end High shaft load up to 450 N Shaft insulation up to 2.8 kV Highest operating speed 10000 rpm Terminal boxes, turn by 180° Redundant sensing

Absolute encoders Magnetic sensing methodFunction display via LEDsMultiturn sensing with Energy Harvesting technology, without gear or batteryTwo-sided bearing system with hybrid bearingsSpecial protection against corrosion C5-M

Incremental encoders Robust industrial encoder up to IP 67 protectionShock resistant up to 200 g'sInsulating insert to prevent high shaft currents from damaging bearingsWide range voltage supply 4.75...30 VDCPrecision ≤60 arc-seconds for perfect process controlMax. 80000 pulses per revolution

Absolute encoders Encoder kit singleturn / AnalogContactless measuring methodFlat designMaintenance-free for the entire service lifeDesigned for harsh environmental conditionsOperating temperature -40...+85 °CResolution: 12 bitRedundant version availableProtection IP 67, radial cable connection

Incremental encoders Size ø58 mmPrecise optical sensingOutput signal level TTL or HTLClamping flangeConnection axial, radial or tangentialPulses per revolution up to 5000High protection up to IP 67High resistance to shock and vibrations

Absolute encoders Absolute encoder multiturnOptical sensing methodMax. resolution: singleturn 18 bit, multiturn 16 bitClamping flangeLED status displayEtherCATMaximum resistant against magnetic fields

Speed switches SIL3 and PLe certificationMonitoring of underspeed, overspeed, standstill and rotating directionInputs for 1 SinCos encoder (SIL3/PLe) and 2 HTL/PNP control signalsSafety related outputsMounting to 35 mm DIN rail (according to EN 60715)USB interface for simple parametrization by the O ...

Incremental encoders Size ø58 mmPrecise optical sensing (interpolated)Output signal level programmable (TTL or HTL)Through hollow shaft, ø8…15 mmConnection radial or tangentialPulses per revolution 1...65536, programmableHigh protection up to IP 67High resistance to shock and vibrations

Tachogenerators Low response timeOpen circuit voltage 10...60 mV per rpmBlind hollow shaft ø12...16 mm or cone shaft ø17 mm (1:10)High signal quality due to patented LongLife technologyHigh protection IP 68Connector outputNo auxiliary energy source required

Hall sensors connector-40 … 85 °C

Incremental encoders - combination Twin encoder featuring two separate systems TTL output driver for cable length up to 550 m Hybrid bearing for extended service life

Absolute encoders Interface CANopen®Magnetic sensing methodResolution: singleturn 13 bit, multiturn 16 bitFunction display via LEDsMultiturn sensing with Energy Harvesting technology, without gear or batteryTwo-sided bearing system with hybrid bearingsSpecial protection against corrosion C5-M

Incremental encoders Robust, compact housing Two bearings with large distance, one at each end High shaft load up to 450 N Shaft insulation up to 2.8 kV Highest operating speed 10000 rpm TTL output driver for cable length up to 550 m Terminal box, turn by 180°

Absolute encoders Interface EtherCATMagnetic sensing methodResolution: singleturn 13 bit, multiturn 16 bitFunction display via LEDsMultiturn sensing with Energy Harvesting technology, without gear or batteryTwo-sided bearing system with hybrid bearingsSpecial protection against corrosion C5-M

Encoders without bearings - absolute Encoder kit singleturn / CANopen®Contactless measuring method, flat designMaintenance-free for the entire service lifeProtection against corrosion CX (C5-M)Operating temperature -40...+85 °CResolution 14 bitRedundant version availableProtection up to IP 69KDete ...

Incremental encoders Size ø58 mmPrecise optical sensingOutput signal level TTL or HTLSquare flange 2.5" (63.5 mm)Connection axial, radial or tangentialPulses per revolution up to 5000High protection up to IP 67High resistance to shock and vibrations

Absolute encoders Absolute encoder multiturnOptical sensing methodMax. resolution: singleturn 18 bit, multiturn 16 bitClamping flangeLED status displayEtherNet/IPMaximum resistant against magnetic fieldsButton for Preset/ResetRotary coding switch for IP address

Programming tools Touchscreen with intuitive navigation1.54“ OLED display (128 x 64 pixels)Simple parameterization of GMM2xxS motion monitorsEditing, saving and loading of parametersDual channel frequency indicatorIndividual scalable process or speed indicators

Incremental encoders Size ø58 mmPrecise optical sensing (interpolated)Output signal level programmable (TTL or HTL)Blind hollow shaft, ø8…15 mmConnection axial, radial or tangentialPulses per revolution 1...65536, programmableHigh resistance to shock and vibrationsOption 0122, Explosion protecti ...

Tachogenerators Open circuit voltage 10...60 mV per rpmSolid shaft ø11 mmEURO flange B10High signal quality due to patented LongLife technologyTemperature compensation of tacho voltage as standardLow moment of inertiaNo auxiliary energy source required

Hall sensors cable FEP, 2 m-40 … 120 °C

Incremental encoders - combination TTL output driver for cable length up to 550 m Electronic speed monitoring Circuit breaker with one selectable threshold speed EURO flange B10 / solid shaft ø11 mm Terminal boxes, turn by 180°

Absolute encoders Interface DeviceNetMagnetic sensing methodResolution: singleturn 13 bit, multiturn 16 bitFunction display via LEDsMultiturn sensing with Energy Harvesting technology, without gear or batteryTwo-sided bearing system with hybrid bearingsSpecial protection against corrosion C5-M

Sine encoders For safety-relevant applications according SIL2Blind hollow shaft ø16 mm or cone shaft ø17 mm (1:10)Up to 5000 sinewaves cycles per turnLow harmonic content (patented LowHarmonics technology)Top-quality SinCos output-signalsProtection against inductive shaft currentLarge terminal box ...

Absolute encoders Interface EtherNet/IPMagnetic sensing methodResolution: singleturn 13 bit, multiturn 16 bitFunction display via LEDsMultiturn sensing with Energy Harvesting technology, without gear or batteryTwo-sided bearing system with hybrid bearingsSpecial protection against corrosion C5-M

Absolute encoders Encoder kit single- or multiturn / CANopen®Precise magnetic sensingAngular accuracy up to ±0.15°Additional incremental signalsHigh protection up to IP 67High resistance to shock and vibrationsElectronic gear function

Incremental encoders Size ø58 mmPrecise optical sensingOutput signal level TTL or HTLSynchro flangeConnection axial, radial or tangentialPulses per revolution up to 5000High protection up to IP 67High resistance to shock and vibrations

Absolute encoders Absolute encoder multiturnOptical sensing methodMax. resolution: singleturn 18 bit, multiturn 16 bitClamping flangeLED status displayPROFINET IOMaximum resistant against magnetic fields

Incremental encoders Encoder with solid shaft ø10 mm or ø6 mmMax. 5000 pulses per revolutionOptical sensing methodClamping or synchro flangeHigh rotation speed up to 10000 rpmCompact designFor safety-relevant applications in compliance with SIL2 (Safety Integrity Level 2)

Incremental encoders Size ø58 mmPrecise optical sensing (interpolated)Output signal level programmable (TTL or HTL)Clamping flangeConnection axial, radial or tangentialPulses per revolution 1...65536, programmableHigh resistance to shock and vibrationsOption 0122, Explosion protection zone 22
